Flexible Stainless Steel Wire Mesh Screen with Aperture 0.02-50.8mm and Wire Diameter 0.02mm-5mm for Industry Filtering

Large Image : Flexible Stainless Steel Wire Mesh Screen with Aperture 0.02-50.8mm and Wire Diameter 0.02mm-5mm for Industry Filtering

Product Details:

Place of Origin:	China
Brand Name:	Kingdelong
Certification:	ISO 9001, ISO 14001, ISO45001, SGS

Payment & Shipping Terms:

Minimum Order Quantity:	30sqm
Price:	$1-$10
Packaging Details:	rolling around paper tube first, moisture-proof paper outside or plastic fabrics, customed packing available
Delivery Time:	5-10 day if in stock
Payment Terms:	T/T,L/C
Supply Ability:	10000sqm/month

Contact Now

Flexible Stainless Steel Wire Mesh Screen with Aperture 0.02-50.8mm and Wire Diameter 0.02mm-5mm for Industry Filtering

Description

Weave Type:	Plain Weave, Twilled Weave, Dutch Weave	Aperture:	0.02-50.8mm
Wire Diameter:	0.02mm-5mm	Edge Treatment:	Raw Edge, Selvadge
Application:	Plain/Twill Weave Stainless Steel Wire Mesh Is Used For Screening And Filtering In Acid Or Alkali Environment. As Mud Mesh In Oil Industry, Chemical Packing Nets, Chemical Fiber Industry As Screen Mesh, Electroplating Industry As Pickling Nets.	Color:	Silver, Balck
Length:	1m-300m	Width:	0.03m-6.5m
Highlight:	Rolls Stainless Steel Wire Mesh Screen , Flexible stainless steel wire mesh screen , Industry Filtering stainless steel mesh screen

Flexible Stainless Steel Wire Mesh Screen In Rolls With Various Weave Types For Industry Filtering Use

Product Overview

Stainless steel wire mesh screen is a versatile material commonly used in various applications like filtration, protection, and separation. The mesh is made of stainless steel wires woven together to form a uniform and durable surface with excellent corrosion resistance, high tensile strength, and good stability in different environmental conditions.

Key Features

High corrosion resistance in extreme temperatures
Exceptional strength and durability
Versatile for wide range of applications with customizable specifications
High temperature resistance for heat or fire applications
Easy to clean and maintain, ideal for food processing and pharmaceutical industries
Excellent visibility and airflow for applications requiring transparency and ventilation
Chemical resistance for use with corrosive substances
Long service life providing cost-effective solutions

Technical Specifications

Our stainless steel wire mesh screens are available in various configurations with customizable technical parameters:

Mesh	Wire Diameter	Opening	Open Area %	Weight per sq.ft
1 x 1	.063"	.937"	87.8	0.255
1 x 1	.080"	.920"	84.6	0.411
1 x 1	.105"	.895"	80.1	0.71
1 x 1	.135"	.865"	74.8	1.177
1 x 1	.162"	.838"	70.2	1.702
1 x 1	.250"	.750"	56.3	4.124
3/4 x 3/4	.054"	.696"	86.1	0.249
3/4 x 3/4	.063"	.687"	83.9	0.34
3/4 x 3/4	.080"	.670"	79.8	0.549
3/4 x 3/4	.105"	.645"	73.9	0.95
3/4 x 3/4	.135"	.615"	67.2	1.581
3/4 x 3/4	.162"	.588"	61.4	2.292
3/4 x 3/4	.250"	.500"	44.4	5.623
2 x 2	.047"	.453"	81.2	0.284
2 x 2	.054"	.446"	79.6	0.376
2 x 2	.072"	.428"	73.3	0.671
2 x 2	.092"	.408"	66.6	1.102
2 x 2	.120"	.380"	57.8	1.896
2 x 2	.148"	.352"	49.6	2.924
2 x 2	.192"	.308"	37.9	5.055

Industry Applications

Our stainless steel wire mesh screens serve diverse industrial needs including:

Filtration and separation in oil/gas, water treatment, pharmaceuticals, and food processing
Screening and sifting in mining, agriculture, construction, and recycling
Architectural and decorative design elements
Security and protection for windows, doors, fencing, and enclosures
Animal enclosures in zoos and aviaries
Heat and flame protection applications
EMI/RFI shielding in electronics and telecommunications
Industrial sieving for grading and sorting materials
Insect and pest control solutions
Medical and laboratory equipment applications
