Product Details:
|
| Product Name: | Square Openings Stainless Steel Welded Wire Mesh Used For Stair Railings | Material: | SS 304, SS 316, Etc |
|---|---|---|---|
| Hole Size: | 1/2''*1'', 1"X1",or As Your Request | Wire: | 0.35-6.0mm |
| Width: | 1m, 1.22m, 1.5m, 2m | Length: | 10m,15m, 20m, 25m, 30m, Also Accept Customed Size |
| Production Process: | Row Welding | Feature: | Easily Assembled, Anti-rust, Anti-corrosion |
| Usage: | Guarding, Railing, Archtectural, Partition Systems | Certification: | ISO, SGS |
| Highlight: | Square Openings Galvanised Welded Mesh,Stair Railings Galvanised Welded Mesh,Square Openings galvanised mesh panels |
||
Welded wire mesh used for stair railings, also called hard wire cloth or welded wire fabric, is manufactured from high-quality stainless steel wire. Featuring square openings with customizable sizes to meet specific requirements, this mesh is available in various wire diameters and opening configurations for diverse applications in agriculture, industry, and architecture. Compared to woven wire mesh, welded wire mesh offers superior stability, a smoother surface, and enhanced strength.
| AISI 304 Stainless Steel Composition | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Grade | C | Si | Mn | P | S | Cr | Ni | T.S. Mpa | EL. % |
| AISI 304 | 0.061 | 0.52 | 1.59 | 0.028 | 0.002 | 18.50 | 9.47 | 580 | 48 |
| AISI 316 Stainless Steel Composition | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Grade | C | Si | Mn | P | S | Cr | Ni | T.S. Mpa | EL. % |
| AISI 316 | 0.01 | 0.360 | 1.200 | 0.019 | 0.001 | 17.360 | 11.800 | 620 | 56 |
Our stainless steel welded mesh features a flat, bright surface with a solid, integrated structure that maintains integrity even when partially cut or under pressure. The material offers exceptional corrosion and oxidation resistance for long-lasting performance.
| Opening | Diameter | Weight | |
|---|---|---|---|
| in. | mm | in. | kg/m² |
| 1/4 x 1/4 | 0.55 | 0.0217 | 1.66 |
| 1/2 x 1/2 | 0.65 | 0.0258 | 1.86 |
| 1/2 x 1/2 | 0.80 | 0.0317 | 1.66 |
| 1/2 x 1/2 | 1.04 | 0.041 | 0.78 |
| 1/2 x 1/2 | 1.57 | 0.062 | 1.22 |
| 1/2 x 1 | 1.04 | 0.041 | 1.32 |
| 1/2 x 1 | 1.45 | 0.057 | 0.70 |
| 1/2 x 1 | 1.57 | 0.062 | 0.47 |
| 5/8 x 5/8 | 1.20 | 0.047 | 1.11 |
| 3/4 x 3/4 | 1.04 | 0.041 | 1.11 |
| 3/4 x 3/4 | 1.45 | 0.057 | 1.27 |
| 3/4 x 3/4 | 1.57 | 0.062 | 1.22 |
| 1 x 1/2 | 1.45 | 0.057 | 0.69 |
| 1 x 1/2 | 1.57 | 0.062 | 1.07 |
Anping Kingdelong Wire Mesh CO. Ltd (KDL) is a professional welded mesh manufacturer with nearly 40 years of industry experience. We specialize in producing all types of welded mesh using black wire, galvanized wire, hot-dipped galvanized wire, SS 304, SS 316, SS 316L wire, and other materials. Our products are ISO1900, ISO14001, and ISO145001 certified, and we can provide SGS testing for custom welded mesh solutions tailored to your specific project requirements.
