Product Details:
|
| Weight Capacity: | 2500LBS | Welded Style: | Spot Welded |
|---|---|---|---|
| Color: | Natural Color Or Painting Color | Aperture: | 1/4" Upto 3" |
| Application: | Construction Wire Mesh, Protecting Mesh, Cages | Wire Dia.: | From 0.8mm Up To 5.5mm |
| Hole Shape: | Square, Rectangular | Netting: | In Panels Or Rolls |
| High Light: | construction spot welded wire mesh panels,3inch aperture welded wire mesh panels,construction spot welded wire fence panels |
||
Our Welded Wire Mesh Panels are a versatile and durable solution for a variety of industrial and commercial applications. Made from high-quality materials and manufactured with precision, these panels provide excellent strength and stability for any project.
Our Welded Wire Mesh Panels are available in a variety of sizes and configurations to meet your specific needs. The Hole Shape can be Square or Rectangular, providing options for different types of applications. The panels are welded together using a Spot Welded style, ensuring a strong and secure connection.
Our Welded Wire Mesh Panels are suitable for a wide range of applications, including but not limited to:
Choose our Welded Wire Mesh Panels for a reliable and cost-effective solution for all your industrial and commercial needs. Contact us today for more information and to request a quote.
| Commonly Used Specifications | ||||
| Mesh Opening in (Center to Center) | Wire Diameter | Panel Size in | Material | |
| in | mm | |||
| 1/4“ | 0.032 | 0.8 | 48" x 1200" | Stainless Steel 304 |
| 1/4“ | 0.025 | 0.6 | 36" x 1200" | Galvanized After |
| 1/2" | 0.041 | 1.0 | 36" x 1200" | Galvanized After |
| 1/2" | 0.041 | 1.0 | 48" x 1200" | Galvanized After |
| 1/2" | 0.063 | 1.6 | 48" x 1200" | Stainless Steel 304 |
| 1/2" | 0.063 | 1.6 | 60" x 1200" | Galvanized After |
| 1/2" | 0.041 | 1.0 | 72" x 1200" | Galvanized After |
| 1/2" | 0.041 | 1.0 | 60" x 1200" | Galvanized After |
| 1" | 0.122 | 3.1 | 72" x 144" | Galvanized After |
| 1" | 0.08 | 2.0 | 48" x 1200" | Pre-Galvanized |
| 1" | 0.063 | 1.6 | 48" x 1200" | Pre-Galvanized |
| 1" | 0.105 | 2.7 | 48" x 96" | Carbon Steel |
| 1" | 0.118 | 3.0 | 48" x 120" | Carbon Steel |
| 1" | 0.118 | 3.0 | 48" x 96" | Carbon Steel |
| 1" | 0.118 | 3.0 | 60" x 120" | Carbon Steel |
| 1" | 0.101 | 2.6 | 48" x 96" | Galvanized After |
| 1" | 0.122 | 3.1 | 48" x 96" | Galvanized After |
| 1-1/2" | 0.135 | 3.4 | 48" x 120" | Carbon Steel |
| 1-1/2" | 0.135 | 3.4 | 60" x 120" | Carbon Steel |
| 1-1/2" | 0.118 | 3.0 | 48" x 96" | Carbon Steel |
| 1-1/2" | 0.118 | 3.0 | 48" x 120" | Carbon Steel |
| 2" | 0.25 | 6.4 | 48" x 120" | Carbon Steel |
| 2" | 0.122 | 3.1 | 72" x 144" | Galvanized After |
| 2" | 0.189 | 4.8 | 48" x 96" | Galvanized After |
| 2" | 0.159 | 4.0 | 48" x 96" | Galvanized After |
| 2" | 0.122 | 3.1 | 72" x 144" | Galvanized After |
| 2" | 0.122 | 3.1 | 60" x 120" | Galvanized After |
| 2" | 0.122 | 3.1 | 48" x 96" | Galvanized After |
| 2" | 0.122 | 3.1 | 48" x 120" | Galvanized After |
| 2" | 0.101 | 2.6 | 48" x 96" | Galvanized After |
| 2" | 0.118 | 3.0 | 48" x 96" | Carbon Steel |
| 2" | 0.118 | 3.0 | 60" x 120" | Carbon Steel |
| 2" | 0.063 | 1.6 | 48" x 1200" | Galvanized After |
| 2" | 0.118 | 3.0 | 72" x 144" | Carbon Steel |
| 2" | 0.135 | 3.4 | 48" x 120" | Carbon Steel |
| 2" | 0.105 | 2.7 | 48" x 96" | Carbon Steel |
| 2" | 0.135 | 3.4 | 48" x 96" | Carbon Steel |
| 2" | 0.118 | 3.0 | .118" | Carbon Steel |
| 2" | 0.135 | 3.4 | 60" x 120" | Carbon Steel |
| 2" | 0.155 | 3.9 | 48" x 96" | Carbon Steel |
| 2" | 0.155 | 3.9 | 60" x 120" | Carbon Steel |
| 2" | 0.187 | 4.7 | 60" x 120" | Carbon Steel |
| 2" | 0.25 | 6.4 | 60" x 120" | Carbon Steel |
| 2" | 0.25 | 6.4 | 48" x 96" | Carbon Steel |
| 2" | 0.118 | 3.0 | 48" x 120" | Carbon Steel |
| 2" | 0.187 | 4.7 | 48" x 120" | Carbon Steel |
| 2" | 0.187 | 4.7 | 48" x 96" | Carbon Steel |
| 3" | 0.162 | 4.1 | 48" x 120" | Carbon Steel |
| 3" | 0.162 | 4.1 | 48" x 96" | Carbon Steel |
| 3" | 0.162 | 4.1 | 48" x 144" | Carbon Steel |
| Product Name | Welded Wire Mesh Panels |
|---|---|
| Aperture | 1/4 |
| Hole Shape | Square, Rectangular |
| Application | Construction Wire Mesh, Protecting Mesh, Cages |
| Wire Diameter | From 0.8mm Up To 5.5mm |
| Netting | In Panels or Rolls |
| Color | Natural Color or Painting Color |
| Packing | On Pallet or In Bulk, Wrapped with Shrink Film |
| Material | Low Carbon Steel, Galvanized Steel, Stainless Steel |
| Weight Capacity | 2500LBS |
| Welded Style | Spot Welded |
| Key Features | Galvanized Wire Mesh Sheets, Welded Metal Mesh Panels, Welded Metal Mesh Panels |
Welded Wire Mesh Panels, also known as Electric Welded Wire Panels or Galvanized Wire Mesh Sheets, are widely used in various fields due to their durability and versatility. These panels are made of high-quality galvanized wire, which is welded together to form a strong and rigid mesh structure. This makes them suitable for a wide range of applications, including construction, protection, and containment.
One of the most common applications of Welded Wire Mesh Panels is in the construction industry. These panels are used for reinforcing concrete structures, such as walls, foundations, and columns. They provide an additional layer of strength and stability, making the structures more resistant to external forces. The panels are also used for creating concrete slabs, making them stronger and more durable.
Moreover, Welded Wire Mesh Panels are also used as formwork for concrete, providing a framework for the concrete to be poured into. This helps in creating a smooth and even surface, ensuring the structural integrity of the concrete.
Welded Wire Mesh Panels are also used for protecting and securing various areas. They can be installed as fences, gates, and barriers to prevent unauthorized access to a property. The rigid structure of the panels makes them difficult to cut or break, providing a high level of security. They are commonly used in residential, commercial, and industrial settings to protect properties, buildings, and equipment.
Besides, Welded Wire Mesh Panels are also used as protective covers for windows, doors, and vents. They are an effective way to prevent intruders, pests, and debris from entering a building while still allowing air and light to pass through.
Another application of Welded Wire Mesh Panels is in the creation of cages for various purposes. The panels can be formed into different sizes and shapes to create cages for animals, storage, and transportation. The strong and durable structure of the panels ensures the safety and security of the enclosed items.
Furthermore, Welded Wire Mesh Panels are also used in the construction of aviaries, poultry runs, and animal enclosures. The panels provide a secure and comfortable environment for the animals while allowing proper ventilation and visibility.
In conclusion, KDL Welded Wire Mesh Panels are a versatile and durable product that can be used in various applications and scenarios. From construction to protection and containment, these panels provide a strong and secure solution for different needs. With its high quality, certifications, and flexible payment terms, KDL is the go-to brand for all your Welded Wire Mesh Panel needs.
Welded wire mesh panels are typically packaged and shipped in the following ways:
Special packaging and shipping options are available upon request to meet specific customer needs.
