Home ProductsSintered Wire Mesh

Black Sintered Wire Mesh Acid Alkali Resistant High Pressure Resistance

I'm Online Chat Now
Certification
China Hebei Reking Wire Mesh Co.,Ltd certification
China Hebei Reking Wire Mesh Co.,Ltd certification
Have the quickly delivery time ,and good quality

—— Michael

Black Sintered Wire Mesh Acid Alkali Resistant High Pressure Resistance

Black Sintered Wire Mesh Acid Alkali Resistant High Pressure Resistance
Black Sintered Wire Mesh Acid Alkali Resistant High Pressure Resistance Black Sintered Wire Mesh Acid Alkali Resistant High Pressure Resistance

Large Image :  Black Sintered Wire Mesh Acid Alkali Resistant High Pressure Resistance Get Best Price

Product Details:

Place of Origin: Hebei,China
Brand Name: R&K
Certification: SGS
Model Number: S-05

Payment & Shipping Terms:

Minimum Order Quantity: 1piece
Price: Negotiate
Packaging Details: Inside:bubble wrap Outside :wooden case or as required
Delivery Time: 5-8 work days
Payment Terms: L/C, D/P, T/T, Western Union,PayPal
Supply Ability: 1000 pieces per week
Detailed Product Description
Material: 304 Stainless Steel Filter Rating: 1 - 200 Um
Technique: Woven Color: Silver / Black
Appication: Filter Weave Style: Plain
High Light:

round wire mesh screen

,

sintered stainless steel sheet

Acid and alkali resistant multilayer stainless steel sintered mesh



Product Description



Sintering can be carried out on most types of woven wire mesh. The main reason for sintering wire mesh is to bond all the wires together to eliminate the migration of the media. Woven meshes are generally prone to edge wear. One square inch of 100 mesh contains 200 wires that are in contact at 10,000 contact points - too much to bond one at a time through any other process! However, if properly sintered, almost every point will melt solidly. Then, even a small disc can be punched from the cloth without wear. This is critical in many applications, such as medical filtration or aircraft hydraulic fluid filtration, where loose wires can cause catastrophic failure. In addition, once the wire is fused, the mesh geometry is permanently fixed. The wire cannot move under pressure, so the aperture size remains stable during use.



Product Feature



• High filtration accuracy based on wire mesh
• Low dropout
• High pressure resistance and excellent toughness
• High heat resistance based on stainless steel characteristics, temperature range -269 ° C ~ 600 ° C
• Excellent corrosion resistance based on stainless steel properties
• Excellent cleanability and long-term reusability due to typical surface filtration



Product Application



• High viscosity liquid filtration, such as polymers and adhesives
• Hot fluid filtration
• Oil filtration, such as lubricating oil and turbine oil
• Fluid food filtration, if juice, cooking oil and vinegar
• Dewatering of sludge, food, etc.



Product Parameters


Note: This list for a reference, not for the complete list.

Nomin

al filter rating

structure prodextive layer+control layer

+dispersion layer+ reinforce layer+ reinforce layer

Thickness(mm) air perm eabilit Bubble pressure(mm)  weight (kg/m2)

  porosity

   (%)

1 100+400*2800+100+12*64+64 1.7 1.81 360-600 5 layer 8.4 40%
5 100+200*1400+100+12*64+64 1.7 2.42 260-550 6 layer 14.4 40%
20 100+165*800+100+12*64+64* 1.7 4.5 170-450   40%
200 40+80+40+20+40+80+40 2 26 50-150   40%
