SS316 Dutch Woven Wire Mesh High Density Acid Resistant Liquid Separation
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Material: | Stainless Steel Wire Mesh | Type: | Weave Wire Mesh |
|---|---|---|---|
| Hole Shape: | Square Shape | Application: | Filter |
| Technique: | Woven | Feature: | Acid-resistant |
| High Light: | barbecue wire mesh,plain dutch weave mesh |
||
Acid-resistant stainless steel Dutch woven wire mesh use to liquid separation
Description of stainless steel Dutch woven wire mesh
Most filtration applications using wire cloth are best done with Dutch weaving. Their warp and weft diameters are different in size and the wefts are close together to provide excellent strength and high density.
Unlike square weaving, the Dutch weave does not have a straight opening. As the fluid continues to travel along a tortuous path, weaving is very effective in releasing and capturing solids from the filter cake.
Application of 60 um stainless steel Dutch wire mesh
Anti-Dutch applications are widely used in aerospace, petroleum, chemical, chemical fiber, machinery, plastic products, scientific research, transportation and other industries.
Feature of the stainless steel Dutch wire mesh
Accurate and uniform aperture
High cleanliness
Excellent formability
High tensile strength
Narrow pore size distribution
Cleanable
Particle-free migration
Good flow rate
Parameters of stainless steel Dutch mesh
|
plain weave Dutch mesh |
||||
|
Number |
Mesh(warpxweft) |
Wire diameter (warpxweft) |
Aperture (um) |
Weight (kg/m2) |
|
32# |
8 x 62 |
0.63mm x 0.45mm |
300 |
5.42 |
|
40# |
10 x 79 |
0.50mm x 0.355mm |
250 |
3.16 |
|
48# |
12 x 64 |
0.58mm x 0.40mm |
280 |
2.9 |
|
55# |
14 x 88 |
0.40mm x 0.30mm |
180 |
2.54 |
|
76# |
19 x 140 |
0.315mm x 0.20mm |
140 |
1.88 |
|
80# |
20 x 300 |
0.35mm x 0.20mm |
- |
3.6 |
|
95# |
24 x 110 |
0.355mm x 0.25mm |
120 |
2.45 |
|
100# |
25 x 140 |
0.28mm x 0.20mm |
100 |
1.95 |
|
120# |
30 x 150 |
0.25mm x 0.18mm |
80 |
1.68 |
|
140# |
35 x 175 |
0.224mm x 0.16mm |
71 |
1.52 |
|
160# |
40 x 200 |
0.20mm x 0.14mm |
60 |
1.40 |
|
180# |
45 x 250 |
0.16mm x 0.112mm |
56 |
1.09 |
|
200# |
50 x 250 |
0.14mm x 0.11mm |
53 |
1.04 |
|
220# |
55.5 x 280 |
0.14mm x 0.10mm |
50 |
0.92 |
|
240# |
65 x 330 |
0.11mm x 0.08mm |
36 |
0.71 |
|
280#(1) |
70 x 350 |
0.11mm x 0.08mm |
35 |
0.72 |
|
280#(2) |
70 x 385 |
0.11mm x 0.07mm |
32 |
0.75 |
|
300# |
78 x 700 |
0.11mm x 0.08mm |
30 |
1.39 |
|
315#(1) |
80 x 400 |
0.10mm x 0.065mm |
40 |
0.62 |
|
315#(2) |
80 x 600 |
0.10mm x 0.06mm |
- |
0.74 |
|
315#(3) |
80 x 800 |
0.15mm x 0.04mm |
- |
0.77 |
|
320# |
81 x 780 |
0.10mm x 0.07mm |
30 |
1.22 |
|
354# |
90 x 550 |
0.12mm x 0.05 |
- |
0.667 |
|
Width:1m-1.6m |
||||
